GE Aestiva/5 MRI Anesthesia Machine
The GE Aestiva/5 MRI is an MRI compatible anesthesia machine. The compact design and small footprint of the Aestiva/5 MRI make it easy to move to either an MRI Suite or an Operating Room when needed. The Aestiva 5 MRI features the standard Datex-Ohmeda user interface like the Aestiva 5, along with ventilation of the SmartVent technology and the advanced breathing system. Coming with two options for ventilators the 7100 and the 7900 SmartVent. The Aestiva 5 MRI comes with an integrated alarm system that warns the operator when the machine is located in an MRI magnetic fringe field in excess of 300 gausses. The GE anesthesia machine offers low and minimal flow anesthesia along with reducing agent consumption.
The GE Aestiva/5 MRI is an MRI compatible anesthesia machine. The compact design and small footprint of the Aestiva/5 MRI make it easy to move to either an MRI Suite or an Operating Room when needed. The Aestiva 5 MRI features the standard Datex-Ohmeda user interface like the Aestiva 5, along with ventilation of the SmartVent technology and the advanced breathing system. Coming with two options for ventilators the 7100 and the 7900 SmartVent. The Aestiva 5 MRI comes with an integrated alarm system that warns the operator when the machine is located in an MRI magnetic fringe field in excess of 300 gausses. The GE anesthesia machine offers low and minimal flow anesthesia along with reducing agent consumption.
The GE Aestiva/5 MRI Anesthesia Machine features:
- Designed for use in MRI settings up to 300 Gauss, active shielded 1.5T and 3T magnets.
- Physically integrated magnetic field strength monitor (Gauss alarm).
- Compact size, small footprint and low overall height takes up minimal space in MRI suites and operating rooms.
- 7900 SmartVent™ with the following ventilation modes: Volume Mode, Pressure Control Mode, Pressure Support (PSVPro®), Synchronized Intermittent Mandatory Ventilation (SIMV), electronic PEEP.
- Ventilator features tidal volume compensation and cardiac bypass case mode.
- Innovative patient breathing system features a responsive location of the common gas outlet.
- Low flow design features a minimum O2 flow of 50 mL.
Dimensions
| Height: | 59.8 in (152 cm) |
|---|---|
| Width: | 38.4 in (97.5 cm) |
| Depth: | 32.7 in (83 cm) |
| Weight: | ~300 lb (136 kg) |
Work Surface
| Height: | 34.5 in (87.6 cm) |
|---|---|
| Width: | 18.5 in (47 cm) |
| Depth: | 12.4 in (31.5 cm) |
Folding Side Shelf (optional)
| Height: | 34.5 in (87.6 cm) |
|---|---|
| Width: | 10.4 in (26.4 cm) |
| Depth: | 12.4 in (31.5 cm) |
| Weight: | 25 lb (11.3 kg) |
DIN Rail (optional)
| Side of tabletop: | 12 in (30.5 cm) |
|---|---|
| Side of machine: | 9.25 in (23.5 cm) |
Casters
| Diameter: | 5 in (12.7 cm) |
|---|---|
| Brakes: | Single foot lever locks and unlocks two front casters |
